Product Name : Flood Jet Spray Nozzles

Flood Jet Spray Nozzles:

Nozzle Descriptions:

Flood Jet Spray Nozzles produce a wide, flat fan jet pattern with uniform distribution and medium impact spray droplets.

They feature a precision-machined deflector surface which provides dependable, accurate control of deflection and spray angle.

The one-piece design resists clogging due to a large, unobstructed flow passage and round orifice.

Flood Jet Spray Nozzles can also be suited to spray air and steam.

Flood Jet Spray Nozzles are also available in the interchangeable tip form, and can be assembled in Uni-jet nozzle.

Design Features:

•    * Nozzle Materials: 303/304 stainless steel, and brass.
•    * Nozzle Structure: one-piece construction no internal filter parts.
•    * Spray Patterns: Flat fan spray.
•    * Spray angles: from 40 to 110 degree.
•    * Pressure Range: 0.2 to 10 bar (0.44 to 60 L/min).
•    * Inlet connection Type: 1/8", 3/8", 1/4", 3/4", 1/2" female and male thread connection.
•    * Also referred to as: Flood Jet Nozzle, Wide-angle spray nozzle.

Flood Jet Spray Nozzles Technical Parameters:

Flood Jet Spray Nozzles Typical Applications:

•   1. Spraying Eliminator Plates;
•   2. Cooling Conveyor Belts;
•   3. Film Washing;
•   4. Water Curtain;
•   5. Fire Protection;
•   6. Washing fruits, vegetables, crushed stones;
•   7. Any other product moving on a conveyor.
